LS1/LS3

THERMOMETERS

IMIT CONTROL SYSTEM

IMIT CONTROL SYSTEM

CAPILLARYSECURITYLIMITERS

CAPILLARY

M10x1

C

2

FASTON 6,3x0,8

28

M

4

LS1 / LS3 is a capillary thermostat with a liquid expansion

probe, unipolar, with safety temperature limiter with man-

ual or automatic reset and with positive safety in case of

capillary breakage. It is particularly suitable for boilers,

heating systems and in all those appliances where it is

necessary not to exceed a maximum set temperature.

Switches = interrupted due to temperature increase

Max. head temperature = 85°C

Copper bulb = 125°C

Copper bulb = Ø 6,5 x 95 mm

Range of thermometers with liquid expansion probe, par-

ticularly suitable for appliance on boilers, refrigerators,

catering appliances, home appliances. The thermometers

are available with different measurement ranges, shapes,

designs and customisable colours.

Code

Article

Casing = plastic

Max. body temperature = 70°C

Certifications = CE, EAC

Description

I

n

d

u

s

t

r

i

a

l

c

o

m

p

o

n

e

n

t

s

I

n

d

u

s

t

r

i

a

l

c

o

m

p

o

n

e

n

t

s

Min. capillary curvature radius = 5 mm

Certifications = CE, ENEC03, EAC, UL

Pack.

010247

THERMOMETER

Circular thermometer 0/120°C, Ø 52mm, Capillary 1500mm PVC, black casing,

white typeface, black screen

50

060107

THERMOMETER

Circular thermometer 0/120°C, Ø 37mm, Capillary 1500mm PVC, black casing,

black typeface, white screen

50

013451

THERMOMETER

Square thermometer 0/120°C, Frame 54*54mm Built-in Ø52mm, Capillary

1500mm PVC, black casing, white typeface, black screen

50

042101

THERMOMETER

Square thermometer 0/120°C, Frame 48*48mm, Capillary 1000mm PVC, black

casing, white typeface, black screen

50

021968

THERMOMETER

Rectangular thermometer 10/105°C, 58 *25mm, capillary 1500mm PVC. Black

casing, black typeface, white screen

50

010836

THERMOMETER

Circular thermometer 50/350°C, Ø 52mm, Capillary 1000mm, black casing,

white typeface, black screen

50

Code

Article

Temperature°C

Capillary

length mm

Electrical

contact capacity

Reset

Pack.

541510

LS1

+90/+110

1000

16(6) A/ 250 V~

MANUAL

100

541550

LS1 INAIL

+100

1000

16(6) A/ 250 V~

MANUAL

100

541563

LS1 INAIL

+100

1500 PVC

16(6) A/ 250 V~

MANUAL

100

541750

LS3

+100

1000

100mv 0.3A cc

AUTOMATIC

100

KIT LS1

CAPILLARY SECURITY LIMITERS

MANOMETERS

CAPILLARY

Range of manometers with capillary connection, particu-

larly suitable for appliance on boilers, fireplaces, heaters

and home appliances. Pressure gauges are available with

different measuring ranges, shapes, designs and custo-

misable colours.

Code

Article

KIT LS1 includes a LS1 100° C with capillary 1500 PVC, INAIL certified, with manual reset, complete with cap and stop.

Working range = 0/6 bar

Casing = plastic

Max. body temperature = 70°C

Certifications = CE, EAC

Description

Code

Article

Description

Pack.

541569

KIT LS1

Single package with LS1, Cap and stop

30

Pack.

035553

MANOMETER

Circular manometer 0/6 bar, Ø 52mm, Capillary 1500mm PVC, M14*1 fitting,

black casing, white typeface, black screen

50

066226

MANOMETER

Circular manometer 0/4 bar, Ø 37mm, Capillary 1500mm PVC,

G1/4” connection, black casing, black typeface, white screen

50

036660

MANOMETER

Square manometer 0/6 bar, Frame 55*55mm, Built-in Ø52mm, Capillary

1500mm PVC, M14*1 fitting, black casing, white typeface, black screen

50
