THERMOMANOMETER
MGR
Range of liquid expansion thermomanometers and con-
nection for manometer. Particularly suitable for appliance
on boilers, fireplaces, heaters and home appliances. Avail-
able in a round version with different measuring ranges
and colours (customisable typeface and dials).
Code
Article
Working range = 0/120°C - 0/6 bar
Casing = plastic
Max. body temperature = 70°C
Certifications = CE, EAC
Description
Plug-in thermostat particularly suitable for electric boilers
Code
Article
Description
Pack.
554760
MGR
Plug-in thermostat 10/80°C Boom L = 280mm
50
I
n
d
u
s
t
r
i
a
l
c
o
m
p
o
n
e
n
t
s
I
n
d
u
s
t
r
i
a
l
c
o
m
p
o
n
e
n
t
s
Pack.
030646
THERMOMANOMETER
Thermomanometer 0/120°C 0/6 bar, Ø 52mm, Capillary 1500 PVC,
M14*1 fitting, black casing, white typeface, black screen
50
ARMORED COPPER RESISTANCE
POCKETS AND
ACCESSORIES
FOR TR2 AND LS THERMOSTATS, THEMOMETERS,
Copper resistors particularly suitable for boilers
Code
Article
BC42
BIMETALLIC THERMOSTAT
Code
Article
Description
Pack.
PRESSURE GAUGES, MANOMETERS
Pockets for the immersion of TR2 and LS thermostats, fittings and tie-rods for coupling to different types of connection and
check valves.
Description
Pack.
550670
RESISTANCE
Threaded copper resistance G1
1⁄4 ‘’ 1200W 230V
50
550680
RESISTANCE
Threaded copper resistance G1 1⁄4 ‘’ 1500W 230V
50
550200
RESISTANCE
Threaded copper resistance G1
1⁄4 ‘’ 2000W 230V
50
555001
Pocket Ø 7*8 mm - L=50 mm - G1/2”
20
555002
Pocket Ø 7*8 mm - L=100 mm - G1/2”
20
555004
Pocket Ø 7*8 mm - L=120 mm - G1/2”
20
555012
Pocket Ø 15*16 mm - L=100 mm contour - G1/2”
20
555014
Pocket Ø 15*16 mm - L=120 mm contour - G1/2”
20
555027
Pocket Ø 7*8 mm - L=200 mm - G1/2”
20
555034
Pocket Ø 15*16 mm - L=100 mm - G1/2”
20
555035
Pocket Ø 15*16 mm - L=120 mm - G1/2”
20
556554
SPRING
Pocket spring 15*16
a.r.
556557
SPRING
External spring
a.r.
556559
SPRING
Pocket spring 7*8
a.r.
501576
BRACKET
Bracket for thermometers and manometers Ø 52mm
a.r.
501578
LATCH
Latch for M4 tie rod
a.r.
501579
LATCH
Latch for M6 tie rod
a.r.
001565
RETENTION VALVE
M14*1 - G1/2” valve
a.r.
001566
RETENTION VALVE
G1/4’’- G1/2’’ valve
a.r.
001567
RETENTION VALVE
G1/4’’ – G1/4’’ valve
a.r.
557205
ADAPTER
G1/4’’ manometer adapter
a.r.
557206
ADAPTER
M14*1 manometer adapter
a.r.
Contact thermostat particularly suitable for fan convectors and fan heaters.
Code
Article
Description
Pack.
557500
BC42
Contact micro-switch, closing temperature 42 °C ± 3.5 °C - opening
temperature 32 °C ± 3.5 °C. - Connection clamps
and stainless steel fixing spring.
10
