IMIT CONTROL SYSTEM

IMIT CONTROL SYSTEM

TC2

TC2 is a boxed immersion thermostat with liquid expan-

sion, unipolar, with changeover switches, complete with

a watertight protection pocket. The thermostat normally

applied on delivery piping is particularly suitable for the

automatic regulation of boilers, pumps and other various

appliances. It is also available in a capillary version.

Code

Article

LSC1

SAFETY LIMITER IN IP40 CONTAINER

LSC1 is a boxed immersion thermostat, with liquid expan-

sion probe, unipolar, safety temperature limiter with man-

ual reset, fail-safe for capillary breakage, complete with

watertight protection pocket. Useful in appliances where

safety is required due to the temperature increase.

Code

Article

TLSC

IMIT CONTROL SYSTEM

REGULATIONTHERMOSTATINIP40CONTAINER

REGULATIONANDSAFETYBI-THERMOSTATINIP40CONTAINER

IMIT CONTROL SYSTEM

55

60

44.5

10

12

10

4

5

7

5

3

0

2

0

9

1

.

5

9

0

1

5

°

C

0

101.5

44.5

10

12

10

60

4

5

7

5

3

0

9

0

1

5

°

C

0

2

0

9

1

1

6

Electrical contact capacity = 10(2,5) A / 250 Vac

Switches = interrupted due to temperature increase or exchange

Max. head temperature = 80°C

Max. bulb temperature = 125°C

Thermal gradient = 1°K/min

Protection rating = IP40

Certifications = CE, ENEC03, DIN, PED, EAC

TLSC is a double boxed immersion thermostat, with liquid

expansion probes, unipolar, temperature regulator and

temperature limiter, fail-safe for capillary breakage, com-

plete with watertight protection pocket. Particularly suita-

ble for appliances where temperature control and safety

is required.

Electrical contact capacity = 10 (2,5) A / 250 Vac

Switches = interrupted due to temperature increase or exchange

Max. head temperature = 80°C

Max. bulb temperature = 125°C

Thermal gradient = 1°K/min

Protection rating = IP40

Certifications = CE, ENEC03, DIN, PED, EAC

Description

Pack.

Code

Article

Description

Pack.

5R2470

TC2 INAIL

Adjustable thermostat 0/90°C, Pocket G1/2’’ L=100

10

542425

TC2 INAIL

Adjustable thermostat 0/90°C, Pocket G1/2’’ L=200

10

542441

TC2

Adjustable thermostat 40/210°C, Pocket G1/2’’ L=100

10

542440

TC2

Adjustable thermostat 40/210°C, Pocket G1/2’’ L=200

10

542562

TC2 INAIL

Adjustable thermostat 0/90°C, Capillary L=1000

10

5R2714

TLSC

Bi-thermostat regulation 0/90°C, safety 90/110°C, Pocket G1/2” L=100

5

5R2731

TLSC INAIL

Bi-thermostat regulation 0/90°C, safety 100°C, Pocket G1/2” L=100

5

T

h

e

r

m

a

l

c

e

n

t

r

a

l

T

h

e

r

m

a

l

c

e

n

t

r

a

l

46

39

2.5

40.5

11.5

5

0

4

0

6

0

3

0

7

0

2

0

90

8

0

2

0

9

9

55

44.5

10

12

10

2

0

9

1

.

5

Electrical contact capacity = 10(2,5) A / 250 Vac

Switches = interrupted due to temperature increase

Thermal gradient = 1°K/min

Max. head temperature = 80°C

Max. bulb temperature = 125°C

Protection rating = IP40

Certifications = CE, ENEC03, DIN, PED, EAC

Description

Pack.

BRC

CONTACT THERMOSTAT

BRC is a bimetallic boxed thermostat, unipolar, with in-

terrupted or changeover switches. Especially suitable for

measuring and regulating temperature.

Code

Article

Differential = 8±3K

Electrical contact capacity = 16(2,5) A / 250 Vac

Thermal gradient = 1°K/min.

Max. head temperature = 80°C

Protection rating = IP20

Certifications = CE, ENEC03, EAC

Description

Pack.

5R5610

BRC

Bimetallic contact thermostat 20/90°C

20

5R5860

BRC

Bimetallic contact thermostat 20/90°C internal regulation

20

543010

LSC1

Safety thermostat 90/110°C, Pocket G1/2” L=120 Manual reset

10

543031

LSC1 INAIL

Safety thermostat 100°C, Pocket G1/2” L=100 Manual reset

10

543151

LSC1

Safety thermostat 90/110°C, Perforated pocket L=230 Manual reset

20
