TCR

TCR is a liquid expansion boxed thermostat, unipolar, with

interrupted or changeover switches, for contact applianc-

es. Particularly suitable for measuring and regulating tem-

perature.

Code

Article

TCS

ADJUSTABLE SAFETY LIMITER IN IP40 CONTAINER

TTCA

IMIT CONTROL SYSTEM

IMIT CONTROL SYSTEM

REGULATIONTHERMOSTATINIP40CONTAINER

REGULATIONBI-THERMOSTATINIP40CONTAINER

58

46

60

5

44

10

4

5

7

5

3

0

2

0

7

2

9

0

1

5

0

°

C

101.5

44.5

10

10

4

0

2

0

6

0

M

A

N

0

C

2

0

9

1

Differential = 10±3K

Max. head temperature = 55°C

Protection rating = IP40

Electrical contact capacity = 10(2,5) A / 250 Vac

Protection rating = IP40

Certifications = CE, ENEC03, EAC

Description

TTCA is a double regulation thermostat for burner control

(internal regulation) and fan start or stop (external regu-

lation).

Electrical contact capacity = 10 (2,5) A / 250 Vac

Adjustable temperature FAN = 0°/60°C

Internal adjustable temperature LIM = 30°/120°C

Protection rating = IP40

Max. head temperature = 80°C

Max. bulb temperature = 150°C

Certifications = CE, ENEC03, EAC

Description

Pack.

Code

Article

Pack.

543451

TCR

Liquid expansion contact thermostat 20/90°C

20

542860

TTCA

Ext. regulation thermostat 0/60°C, int. regulation 30/120°C,

with perforated pocket 16*120mm

5

542870

TTCA

Ext. regulation thermostat 0/60°C, int. regulation 30/120°C,

with perforated pocket 16*230mm

5

542873

TTCA

Ext. regulation thermostat 0/60°C, int. regulation 30/120°C,

with 12*280mm boom pocket

5

542833

TTCA

Ext./int. regulation thermostat 0/90°C, with G 1⁄2” pocket 15*16*100mm

5

T

h

e

r

m

a

l

c

e

n

t

r

a

l

T

h

e

r

m

a

l

c

e

n

t

r

a

l

ETR

REGULATION THERMOSTAT IN IP54 CONTAINER

58

5

44

5

46

2

0

7

2

75.5

3

39

10.5

62

30

4

0

2

0

2

0

9

6

3

6

.

5

5

0

1

0

0

TCS adjustable safety limiter in Ip40 container TCS is a liq-

uid expansion boxed safety thermostat, unipolar, with in-

terrupted contacts. Especially suitable for appliances and

for securing temperature.

Code

Article

Temperature limiter pre-regulation = 60°C

Regulation range = 40°÷70°C

Tolerance = 0-10K

Manual reset

Reset temperature = -25K ± 8K range

Max. head temperature = 55°C

Electrical contact capacity = C-1: 0,5 A / 250 Vac C-2: 10(2,5) A / 250

Vac

Protection rating = IP40

Certifications = CE, ENEC03, EAC

Description

Pack.

ETR is an adjustable boxed thermostat for controlling

temperature in various appliances, especially suitable for

environments with a high degree of pollution. Protection

rating IP54.

Differential = from 3 to 6°C

Electrical contact capacity = 16(2,5) A / 250 Vac

Max. operating temperature = 65°C

Protection rating = IP54

Certifications = CE, ENEC03, EAC

Description

Code

Article

Pack.

543454

TCS

Safety liquid expansion contact thermostat 40/70°C

20

544400

ETR

Regulation thermostat 0/55°C with joined nickel-plated bulb 9.5*92mm

5

544401

ETR

Regulation thermostat -35/+35°C with joined nickel-plated bulb 9.5*92mm

5

544402

ETR

Regulation thermostat -35/+35°C with 2000mm nickel-plated capillary

5
