TA3

TA3 is a mechanical wall thermostat with saturated steam

expansion tank, ideal for regulating home or office tem-

perature. It is available in LED versions, without LED, ON /

OFF (to turn off the thermostat without turning the knob),

Summer / Winter (to connect and regulate the air condi-

tioning or heating system). This thermostat also offers the

possibility to limit or block the set temperature, through the

installation of an optional switch under the cover.

Code

Article

TA5

MECHANICAL WALL-MOUNTED THERMOSTAT

SILVER TA S

DIGITAL ROOM WALL-MOUNTED THERMOSTAT

Also available

IMIT CONTROL S

NTROL SYSTEM

MECHANICAL WALL-MOUNTED THERMOSTAT

124

Electrical contact capacity = 16(2,5) A / 250 Vac

Regulation range = 5°÷30°C

Differential = 1K

Insulation class = II

Protection rating = IP20

Max. tolerance temperature = 50°C

Connection = 2 wires

Output = changeover switches

Operating mode: On/Off or Summer/Winter

System: heating/air conditioning

Certifications: CE, ENEC03, EAC

Description

Pack.

in radio version

SILVER TA S is a digital room thermostat with TPI algorithm,

ideal for regulating heating or cooling. The backlit LCD dis-

play clearly shows the detected room temperature, set

temperature, active operating mode, status icons and flat

battery warning. The external knob makes temperature

regulation even more immediate. Includes the Antifreeze

function and allows temperature calibration with a range

of ±8°C.

Code

Article

Operating current: 3V DC (2 AAA alkaline batteries)

Relay NO Switching current:

2A/30VDC (Resistive load) 2A/250VAC (Resistive load)

Temperature measurement accuracy: 0.1°C

Operating sensitivity: 0.5°C

Operating temperature range: 5°÷30°C

Battery life: 1 year (2 x AAA)

Operating temperature: -10°÷50°C

Storage temperature: -20°÷60°C

Description

546070

TA3

3-contact thermostat

20 546030

TA3-A

3-contact thermostat-LED indicator light

20 546010

TA3-B

3-contact thermostat - LED indicator light - ON / OFF switch

20 546230

TA3-C

2-contact thermostat - LED indicator - summer winter switch

20 000071

SWITCH

Switch for knob lock

a.r.

004095

BOTTOM PIECES

Bottom pieces for TA3 in black

a.r.

Pack.

578811

SILVER TA S

Digital room thermostat

5 578816

SILVER TA/RF S

Radio digital room thermostat (433 Mhz)

5

CHRONOMIX S

DAILY WALL-MOUNTED PROGRAMMABLE THERMOSTAT

145

TA5 is a mechanical wall thermostat with saturated steam

expansion tank, ideal for regulating home or office tem-

perature. It is available in LED versions, without LED, ON /

OFF (to turn off the thermostat without turning the knob),

Summer / Winter (to connect and regulate the air condi-

tioning or heating system). This thermostat also offers the

possibility to limit or block the set temperature, through the

installation of an optional switch under the cover. Thanks

to the new external ergonomic knob, temperature regula-

tion is simple and accessible to everyone.

Code

Article

Electrical contact capacity = 16(2,5) A / 250 Vac

Regulation range = 5°÷30°C

Differential = 1K

Insulation class = II

Protection rating = IP20

Max. tolerance temperature = 50°C

Connection = 2 wires

Output = changeover switches

Operating mode: On/Off or Summer/Winter

System: heating/air conditioning

Certifications: CE, ENEC03, EAC

Description

CHRONOMIX-S is an electronic daily programmable ther-

mostat that is extremely simple and intuitive. Through a

switch clock you may choose which one of the two levels

of temperature to activate at a certain time. It is ideal for

regulating home or office temperature, through the two

knobs that manage comfort or reduced temperature, per-

fect for the regulation of different temperatures during the

day and night or during your absence. Easy to set up, but

highly technological, thanks to its TPI operation that allows

exploiting thermal inertia in every type of environment,

Electrical contact capacity = 5(1) A / 250 Vac

Temperature range = 10°÷30°C

Differential = 0.5 K

Insulation class = II

Protection rating = IP20

Max. room temperature = 50°C

Power supply = 2 x 1.5V-LR6 AA batteries

Operating mode: Manual / Automatic

Heating system

Form of control: TPI (optional)

Certifications = CE, ENEC03
