TECHNO DUO

TECHNO DUO is a programmable electronic daily switch

thermostat. The LCD display (backlit blue) shows the room

temperature, set time or temperature, daily programming,

active mode of operation and low battery indicator. The

automatic program can be set

to half an hour or an hour. It memorises the anti-freeze

threshold and two temperature levels (comfort and re-

duced, day and night), and regulates both the air condi-

tioning and heating systems, through the three modes of

operation: Manual/Automatic/Anti-freeze. The TPI function

(optional) allows exploiting thermal inertia in every type of

environment, guaranteeing absolute comfort, and energy

and economic savings and an ErP contribution of 4%. Ideal

for those who want constant programming during the we-

ek or for those who have difficulty with technology.

Code

Article

SILVER CR-W

Also available

in radio version

ORION WIFI

WEEKLY WALL-MOUNTED PROGRAMMABLE THERMOSTAT

New in 2025

IMIT CONTROL S

NTROL SYSTEM

DAILY WALL-MOUNTED CHRONOTHERMOSTAT

139.5

34.5

83

28

0

1

6

2

/

1

2 1

8

2

/

1

2

10

12

14

16

18

20

22

5/

7/

5

6

7

8

9

11

13

15

17

19

21

23

10

15

20

5

30

25

Set /

Mode

9

7

.

5

6

0

136

128

29

83

9

3

8

4

6

0

Electrical contact capacity = 5(1) A / 250 Vac

Regulation range = 5°÷35°C

N° of settable temperatures = 2

Time slots = 0.5 h e 1 h

Differential = 0,2 K

Thermometer resolution = 0,1°C

Thermometer precision = ±0,3°C

Max. room temperature = 50°C

Insulation class = II

Protection rating = IP20

Options = 12h/24h clock and °C/°F selection

Operating mode: Manual/Automatic/Anti-freeze

System: heating/air conditioning

Form of control: TPI (optional)

Certifications = CE, ENEC03

Description

The Orion WIFI chronothermostat is the ideal solution for

those who want precise and convenient control of the home

temperature. Thanks to the WIFI connection, you can mana-

ge the heating and cooling of the home directly from your

smartphone or PC, wherever you are.

Key Features:

Power supply = 230 V ac

Type of regulation = Selectable during installation

ErP class = IV (-2%) in ON/OFF mode with TPI

ErP class I (-1%) in traditional ON/OFF mode

Type of system = Heating/Air conditioning

Operating modes = Manual / Automatic / Antifreeze

Type of programming = Weekly on 2 temperature levels

Minimum programming time slot = 30 minutes

Maximum contact capacity = 5A (1A) 250Vac

Temperature regulation range = 5.0°C -35.0°C

Tolerance 0.3 K

Differential = Adjustable between 0.1 and 2.0 K (Standard 0.2 K)

Backlit display with adjustable intensity

Web-App compatible with systems: Android-iOS-Alexa-Google

Certifications = CE

60

Pack.

• Remote Control: Adjust your home temperature via the Web App independent of the various updates of iOS and Android

systems.

578160

TECHNO DUO

Daily chronothermostat with switch clock and LCD display

5

124

20

60

8

4

SILVER CR-W is a programmable digital weekly chro-

nothermostat. The backlit LCD display shows the detected

temperature, time and set temperature, active operating

mode and the time programming in use. It offers 3 diffe-

rent preset programs (Comfort, Economy and Holiday) as

well as the possibility of setting a customized manual or

weekly program, on two temperature levels (comfort and

reduced).

It includes the TPI modulation function, allowing to reach

the ErP IV class, also present the antifreeze function, allows

the temperature calibration with a range of ±8°C.

Code

Article

Power supply: 3 Vdc (2 x AAA alkaline batteries)

Switching current: 2A (230 Vac) Relay NO

Temperature measurement accuracy: 0.1°C

Differential: 0.3°C.

Operating temperature range: 5°÷30°C

Battery life: 1 year (2 x AAA)

Operating temperature: -10°÷50°C

Storage temperature: -20°÷60°C

Description

Code

Article

Description

Pack.

WEEKLY WALL-MOUNTED PROGRAMMABLE THERMOSTAT

• Weekly Programming: Set custom heating programs for each day of the week.

• Compatibility: Works with most heating and cooling systems.

• Modern Design: Backlit display (with adjustable intensity) and elegant design that adapts to any environment.

Advantages:

• Comfort: keeps your home at the ideal temperature at all times.

• Efficiency: reduces energy consumption.

• Ease of use: simple installation and intuitive use thanks to the user-friendly app.

• Updates: automatic reception of software for new features and improvements; in addition to automatic synchronization of

the time and day of the week.

• it is possible to configure more than one chronothermostat in the same home, especially if you have different areas or floors

that you want to control separately.

• Configuration via the Web-App to add and configure each chronothermostat.

• Individual programming: set customized heating/cooling programs for each area based on your needs.

• Configuring multiple chronothermostats allows you to have more precise control and optimize comfort and energy effi-

ciency in every part of the home.

Note:

• You can use the chronothermostat even without a WIFI connection, but with some limitations. Without WIFI, you can still:

• Manually adjust the temperature: using the controls on the device itself.

• Set heating programs: directly on the chronothermostat.

Warning: for the appliance to work, you need a WiFi router (fixed or mobile network), a PC (Windows or Os) and/or a smar-

tphone (Os or Android).

578842

ORION WI FI

ORION WI FI Weekly Programmable Thermostat Wi Fi

5

Pack.

578827

SILVER CR-W

Weekly Programmable Thermostat

5

578829

SILVER CR-W RF

Weekly radio Programmable Thermostat

5
