Imit Control System - Product range

IMIT CONTROL SYSTEM

IMIT CO

YSTEM

ORION DAY

ORION WEEK

WEEKLY WALL-MOUNTED PROGRAMMABLE THERMOSTAT

Also available

IMIT CONTROL S

NTROL SYSTEM

DAILY WALL-MOUNTED PROGRAMMABLE THERMOSTAT

136

128

136

128

ORION DAY is a digital daily Programmable Thermostat, also

available in radio version. Thanks to the TPI logic, it exploits

the thermal inertia of any type of environment, for absolute

comfort, energy savings and an ErP IV contribution up to 2%.

It combines simplicity of programming with energy saving,

with 2 temperatures that can be set in 30-minute steps.

Thanks to the large backlit LCD display, it’s possible to vis-

ualize the detected temperature, time or set temperature,

and operating modes: Auto (Comfort-Eco)/Manual/Anti-

freeze (Off). The 24 hourly micro-pushbuttons and the oth-

er controls are easily accessible, but protected by a clean

cover which makes them suitable for any installation envi-

ronment. It is ideal for those who have different habits de-

pending on the time of day or have environments that they

use at different times of the day.

Code

Article

ORION DAY OT

Power supply = 2x1.5V AAA type alkaline batteries (lasting > 1 year)

Type of regulation = Selectable during installation

ErP class = IV (-2%) in ON/OFF mode with TPI

ErP class = I (-1%) in traditional ON/OFF mode

Type of system = Heating/Air Conditioning

Operating modes = Manual / Automatic / Antifreeze

Type of Programming = Daily on 2 temperature levels

Minimum programming time slot = 30 minutes

Contact maximum rating = 5A (1A) 250Vac (ON/OFF mode only)

Temperature setting range = 5.0-35.0 °C

Tolerance +/- 0.3K

Differential = Adjustable between 0.1 and 2.0K (Standard 0.2K)

Options = Clock format 12/24H

Backlit display

Maximum ambient temperature = 50°C

Storage temperature = -25°C ÷ 60°C

Insulation class = Type II (Double insulation)

Degree of protection = IP20

Approvals = CE

Power supply = 2x1.5V AAA type alkaline batteries (Duration > 1 year)

Type of regulation = Selectable during installation

ErP class = IV (-2%) in ON/OFF mode with TPI

ErP class I (-1%) in traditional ON/OFF mode

Type of system = Heating/Air Conditioning

Operating modes = Manual / Automatic / Antifreeze

Type of Programming = Weekly on 2 temperature levels

Minimum programming time slot = 30 minutes

Contact maximum rating = 5A (1A) 250Vac (ON/OFF mode only)

Temperature setting range = 5.0°C -35.0°C

0.3K tolerance

Differential = Adjustable between 0.1 and 2.0K (Standard 0.2K)

Options = Clock format 12/24H

Backlit display

Maximum ambient temperature = 50°C

Storage temperature = -25°C ÷ 60°C

Approvals = CE

Also available

in radio version

ORION WEEK is a weekly digital Programmable Thermostat,

also available in radio version. Thanks to the TPI logic, it ex-

ploits the thermal inertia of any type of environment, for ab-

solute comfort, energy savings and an ErP IV contribution up

to 2%. It combines simplicity of programming with energy

saving, with 2 temperatures that can be set in 30-minute

steps.

Thanks to the large backlit LCD display, it is possible to vis-

ualize the detected temperature, time or set temperature,

and operating modes: Auto (Comfort-Eco)/Manual/Anti-

freeze (Off). The 24 hourly micro-pushbuttons and the oth-

er controls are easily accessible, but protected by a clean

cover which makes them suitable for any installation envi-

ronment. It is ideal for those who have different habits de-

pending on the day of the week or have environments that

they use at different times of the day.

Code

Articolo

Description

DAILY WALL-MOUNTED PROGRAMMABLE THERMOSTAT

OPENTHERM IN CLASS V

Pack.

Description

Pack.

578830

ORION DAY

ORION DAY Daily On/Off

5 578831

ORION DAY/RF

ORION DAY/RF Daily On/Off Radio (868.2 Mhz)

5 578840

ORION WEEK

ORION WEEK Weekly On/Off

5 578841

ORION WEEK/RF

ORION WEEK/RF Weekly On/Off Radio (868.2 Mhz)

5

ORION WEEK OT

WEEKLY WALL-MOUNTED PROGRAMMABLE THERMOSTAT

OPENTHERM IN CLASS V

136

128

136

128

ORION DAY OT is a Class V ErP digital daily Programmable

Thermostat, which uses the OpenTherm communication

protocol. It combines simplicity of programming with ener-

gy savings up to 4% on each bill, with 2 temperatures that

can be set in 30-minute steps.

Thanks to the large LCD display, it is possible to visualize the

detected temperature, time or set temperature and oper-

ating mode: Auto (Comfort-Eco)/Manual/Antifreeze (Off).

The 24 hourly micro-pushbuttons and the other controls

are easily accessible, but protected by a clean cover which

makes them suitable for any installation environment. It is

ideal for those who have different habits depending on the

time of day or have environments that they use at different

times of the day.

Power supply = via BUS cable from Opentherm boiler

ErP class = V (- 4%) in OpenTherm mode

Type of system = Heating/Air Conditioning

Operating modes = Manual / Automatic / Antifreeze

Type of Programming = Daily on 2 temperature levels

Minimum programmable time slot = 30 minutes

Contact maximum rating = 5A (1A) 250Vac (ON/OFF mode only)

Temperature setting range = 5.0-35.0°C

Differential = Adjustable between 0.1 and 2.0K (Standard 0.2K)

Options = Clock format 12/24H

Backlit display = only if combined with OPENTHERM boilers

Compatible

Storage temperature = -25°C ÷ 60°C

Approvals = CE, OPENTHERM

ORION WEEK OT is a Class V ErP digital weekly Programma-

ble Thermostat, which uses the OpenTherm communication

protocol. It combines simplicity of programming with ener-

gy savings up to 4% on each bill, with 2 temperatures that

can be set in 30-minute steps.

Thanks to the large LCD display, it is possible to visualize

the temperature detected, the time or temperature set,

the active day of the week and the operating mode: Auto

(Comfort-Eco)/Manual/Antifreeze (Off). The 24 hourly mi-

cro-pushbuttons and the other controls are easily acces-

sible, but protected by a clean cover which makes them

suitable for any installation environment. It is ideal for those

who have different habits depending on the day of the week

or have environments that they use at different times of the

day.

Power supply = via BUS cable from Opentherm boiler

ErP class = V (- 4%) in OpenTherm mode

Type of system = Heating/Air Conditioning

Operating modes = Manual / Automatic / Antifreeze

Type of Programming = Weekly on 2 temperature levels

Minimum programmable time slot = 30 minutes

Contact maximum rating = 5A (1A) 250Vac (ON/OFF mode only)

Temperature setting range = 5.0°c 35.0 °C

Differential = Adjustable between 0.1 and 2.0K (Standard 0.2K)

Options = Clock format 12/24H

Backlit display = only if combined with OpenTherm boilers

compatible

Storage temperature = -25°C ÷ 60°C

Approvals = CE, OPENTHERM
