TAE/503S

TAE/503S is a DIN503 built-in room thermostat, ideal for

regulating the temperature of your home or office. It can

manage both the air conditioning and heating systems

and the three operating modes Summer/Winter/Antifreeze

are very simple to set, thanks to the practical knob for reg-

ulating the temperature. An LED signals low batteries. It is

ideal for small rooms, when temperature programming

is not necessary or to manage temperature variations in

delimited areas. The package includes 4 interchangeable

frames for use with the majority of aesthetic switch plates

on the market and an additional front panel + knob that

allow you to vary the color (white/black) of the device.

Code

Article

CRD/503S

BUILT-IN WEEKLY PROGRAMMABLE THERMOSTAT

IMIT CONTROL S

NTROL SYSTEM

BUILT-IN ELECTRONIC ROOM THERMOSTAT

Electrical contact capacity = 8(5) A / 250 Vac

Regulation range = 5°÷30°C

Power supply = 2 x 1.5V-LR6 AA batteries

Max. room temperature = 50°C

Insulation class = II

Protection rating = IP40

Operating mode: Summer/Winter/Anti-freeze

System: heating/air conditioning

Certifications = CE

Description

CRD/503S is a programmable built-in weekly programma-

ble thermostat DIN503 with three programmable temper-

atures at intervals of 1 hour. It is ideal for managing the

temperature of your home or office and can regulate both

the air conditioning and heating systems. Thanks to the

backlit LCD display you can display the measured temper-

ature, set temperature, time, active day and the operating

mode: Manual/Automatic/Anti-freeze.

It is ideal for those with different habits depending on the

day of the week or for those who have environments that

they use at different times of the day. The package in-

cludes 4 interchangeable frames for use with most aes-

thetic switch plates on the market and an additional front

panel that allows you to vary the color (white/black) of the

device.

Code

Article

Electrical contact capacity = 8(5) A / 250 Vac

Regulation range = 5°÷35°C

Power supply = 2 x 1.5V-LR6 AA batteries

N° of settable temperatures = 3

Time slots = 1 h

Thermometer precision = ±0,3°C

Max. room temperature = 50°C

Insulation class = II

Protection rating = IP40

Operating mode: Manual/Automatic/Anti-freeze

System: heating/air conditioning

Certifications = CE

Pack.

Description

Pack.

560065

TAE/503S

Built-in room thermostat, AA battery power supply

10

560085

CRD/503S

Weekly built-in Programmable Thermostat, AA battery power supply

10

DUO/503S

BUILT-IN DAILY PROGRAMMABLE THERMOSTAT

ACCESSORIES

FOR BUILT-IN THERMOSTATS

DUO / 503S is a built-in programmable DIN503 thermostat

with switches. It is ideal for regulating the temperature of

the home or office and can manage both the air condi-

tioning system and heating systems. Thanks to the backlit

LCD display you can display the measured temperature,

set temperature, time and the active mode of operation:

Manual/Automatic/Anti-freeze. Time programming at 1

hour intervals is carried out via the practical mechanical

switches. It is ideal for those who want to have simple and

constant programming during the week or for those who

have difficulty with technology. The package includes 4 in-

terchangeable frames for use with most aesthetic switch

plates on the market and an additional front panel that

allows you to vary the color (white/black) of the device.

Code

Article

Electrical contact capacity = 8(5) A / 250 Vac

Regulation range = 5°÷35°C

Power supply = 2 x 1.5V-LR6 AA batteries

N° of settable temperatures = 2

Time slots = 1 h

Thermometer precision = ±0,3°C

Max. room temperature = 50°C

Insulation class = II

Protection rating = IP40

Operating mode: Manual/Automatic/Anti-freeze

System: heating/air conditioning

Certifications = CE

Description

Kit of aesthetic-plates for built-in DIN503, glossy black colour.

Code

Article

FRAME COMPATIBILITY WITH PLATES

FRAME A COMPATIBILITY

FRAME B2 COMPATIBILITY

Description

FRAME C COMPATIBILITY

Pack.

FRAME D COMPATIBILITY

557022

PLATES KIT

Set of 5 glossy black aesthetic-plates

a.r.

IMIT

Bticino Light, Light tech,

Living international, Matrix.

Vimar Idea, Idea Rondò.

Gewiss Playbus,

Playbus young.

Ave Banquise, Sistema 45,

Noir.

Siemens Delta futura

Legrand Ergo, Cross, Vela.

Bticino Luna, Axolute,

Living now.

Vimar Plana, Eikon,

Eikon Evo.

Gewiss Chorus.

Master Modo, Mix.

Bticino Living Light air,

Axolute Air.

Ave sistema 44.

Vimar Arch

è.

EC Elettrocanali Prestige,

Life.

Pack.

560075

DUO/503S

Daily built-in Programmable Thermostat, AA battery power supply

10

12

13
