TECHNICAL DATA
Order no.
Dimensions (WxHxD)
Matching for washbasin
Specification
Weight
Accessories excl.
4
0515.0 / without cut out
4
0515.1 / 1 cut out
1581 x 80 x 520 mm
see matrix for washtops 1581 mm
Body – MDF board with PVC foil
without or with cut out
with 3 mounting brackets
max. load 150 kg
20,5 kg
For possible drawer elements Case see matrix.
Towel rail, anodized aluminium, order no. 49095.2
Mounting acc. incl.
Mounting information
Colours body
Installation set, order no. 49012.4
and mounting brackets
The walls installed on must meet the require-
ments of the furniture in terms of weight and
the supplied fastening elements. If this cannot
be guaranteed another method of installation
needs to be chosen.
463 – White
519 – Chalked oak
548 – Anthracite oak
CASE
Washtop without / with cut out
40515.0
40515.1
TECHNICAL DRAWINGS / S 1 : 20
A
7
0
70
70
37
70
70
70
37
B
1581
A / mm
477
477
477
477
477
477
447
477
477
477
B / mm
Ceramic
Kartell by Laufen 81333.2
Palomba 81680.1
Kartell by Laufen 81233.2 (with tap bank left)
Kartell by Laufen 81033.8
Val 81228.2 (semi-wet-area right)
Val 81628.8
Palomba 81680.2
Kartell by Laufen 81033.4
Val 81228.1
Palomba 81680.3
A / mm
347
347
477
347
347
477
B / mm
Ceramic
Kartell by Laufen 81033.5
Living City 81743.7, 81843.8
Living Square 81643.4
Laufen Pro S 81696.4, 81696.5, 81696.6, 81696.7
Val 81628.5, 81628.7
Val 81228.2 (semi-wet-area left)
Kartell by Laufen 81033.9
Kartell by Laufen 81233.2 (with tap bank right)
all other from matrix for washtops Case
491
565
584
641
687
698
702
716
740
741
865
790,5
894
940
995
790,5
X = The exact height must be set during installation.
