TECHNICAL DATA

Order no.

Certified to

matching for

Specification

Water inlet

Weight

Mounting acc. incl.

Mounting acc. excl.

Colours

8

2654.2

EN 14055

Floorstanding WC pan, order no. 82454.1,

8

2454.2

Wallhung WC pan, order no. 82054.5, 82054.9

Flushing mechanism Dual-Flush

With water condensation insulation:

Charge 872 – 6/3-l-flush

side left, side right, 3/8” brass

13,0 kg

Fastening kit

Angle valve for water inlet

Water inlet hose

see colour table

SPECIFICATION TEXT

Cistern Laufen-MODERNA R, sanitary ceramic

EN 14055, dimensions 380 x 175 x 400 mm

Dual-Flush 6/3-l

water inlet side left, side right, 3/8” brass

matching floorstanding WC pan order no. 82454.1, 82454.2 and

wallhung WC pan order no. 82054.5, 82054.9

Special feature: with water condensation insulation

Order no. 82654.2

SET MODERNA R

Cistern

82654.2

TECHNICAL DRAWINGS / S 1 : 20

380

175

60

Z 180301

3

0

0

4

0

0

3

3

0
