CODE 4005
Ti a 90°
F
H
E
C
B
D
A
CODE
DIM
[mm]
A
[mm]
B
[mm]
C
[mm]
D
[mm]
E
[mm]
F
[mm]
H
[mm]
PACK
BAG [UMV]
OT1
OT2
4005160000001
16x16x16
84
42
42
42
16x2,0
16x2,0
16x2,0
2
20
-
4005180000001
18x18x18
88
44
44
44
18x2,0
18x2,0
18x2,0
2
16
-
4005200000001
20x20x20
90
45
45
45
20x2,0
20x2,0
20x2,0
2
16
-
4005260000001
26x26x26
94
47
47
47
26x3,0
26x3,0
26x3,0
2
10
-
4005320000001
32x32x32
116
58
58
58
32x3,0
32x3,0
32x3,0
2
8
-
4005400000001
40x40x40
146
73
73
73
40x3,5
40x3,5
40x3,5
1
4
-
4005500000001
50x50x50
178
89
89
89
50x4,0
50x4,0
50x4,0
1
-
7
4005630000001
63x63x63
198
99
99
99
63x4,5
63x4,5
63x4,5
1
-
4
CODE 4029
Ti a 90° con derivazione maggiorata
F
B
D
A
H
C
E
CODE
DIM
[mm]
A
[mm]
B
[mm]
C
[mm]
D
[mm]
E
[mm]
F
[mm]
H
[mm]
PACK
BAG [UMV]
OT1
4029162016001
16x20x16
90
45
42
45
16x2,0
20x2,0
16x2,0
2
16
4029202620001
20x26x20
96
48
56
48
20x2,0
26x3,0
20x2,0
2
12
