ACCESSORI Accessories

FC & FCV - ATX

NB: accessori non contemplati nel Certi

ficato di Esame del Tipo. Contattare il servizio tecnico-commerciale per esigenze costruttive diverse.

NB: accessories not included in the Type Examination Certificate. Please contact us for any different construction requirments.

SILENZIATORI (GR) - SILENCERS (GR)

Silenziatori con setto centrale, riducono la rumorosit

à del torrino

in aspirazione. Materiale fonoassorbente in lana minerale. Strut-

tura portante in lamiera zincata. Attenzione: l’utilizzo del silen-

ziatore abbinato alla serranda TS, richiede una versione speciale

dotata di setto centrale ridotto (Da speci

ficare in fase d’ordine).

Silencers with central pod. They reduce the exhausting noise of

the fan. Sound absorbing material: mineral wool. Frame in gal-

vanized steel sheet. Attention: the use of a Silencer together with

a TS shutter requires special version of the silencer itself, with a

reduced pod. Please mention it when ordering the silencer.

Cod.

Tipo / Type

1SI0310 GR 25 / 31

1SI0350 GR 35

1SI0400 GR 40 / 45

1SI0560 GR 50 / 56

1SI0630 GR 63 / 75 / 80

A

B

C

D

E

F

G

ØH kg

Tipo/Type

GR 25 / 31

GR 35

GR 40 / 45

GR 50 / 56

GR 63 / 75 / 80

63

125 250 500 1000 2000 4000 8000

2

4

6

1

0

1

6

1

8

1

5

11

3

5

9

1

1

1

9

2

0

1

8

14

3

4

8

9

1

8

1

5

1

0

6

4

5

1

1

1

5

1

6

1

2

9

5

3

4

5

8

14

9

7

3

Attenuazione in dB per banda di ottava (HZ)

Octave (HZ) spectrum of noise attenuation in dB

SERRANDE A GRAVITÀ (TS) - GRAVITY SHUTTER (TS)

Evitano inutili dispersioni di calore e richiedono un’irrilevante perdi-

ta di carico. Le alette della serranda si aprono con la depressione

dell’aria generata dal ventilatore in moto e si chiudono per gravità al

suo spegnimento. La struttura è realizzata in lamiera zincata.

They avoid heat dispersion through the roof when this fan is not working

with a negligible opening pressure. The shutter flaps are opened by the air

depression produced by the fan when working, and they shut down by gra-

vity after switching-off. The structured is made in galvanized steel sheet.

CONTROBASI A MURARE (CB) - COUNTER BASES TO BE WALLED UP (CB)

La controbase garantisce un efficace ancoraggio al cavedio, tramite la muratura delle quattro zanche appositamente realizzate.

Manufatto realizzato in robusta lamiera con predisposto il fissaggio alla base del torrino.

The counter base ensures an effective anchorage to the concrete support, through the

fixing of four metal strips suitably designed.

It is made in solid steel with arrangement for fixing to the fan base.
