ES 5941Z

Info and menu parameters

SEK03

DHW COLD

WATER TEMP

Domestic

cold water

temperature

TKW

Display for the current domestic

cold water inlet temperature

on the secondary plate heat

exchanger.

0...120

°C

0

00:068

SEK04

FLOW RATE

DHW

Flow rate

FLOW

Display for the current water flow

rate on the secondary plate heat

exchanger.

0...999.9

l/min

0

00:069

SEK05

CIRCULATION

TEMP

Circulation

temperature

TBZ

Display for the current circula-

tion temperature, local value

according to the choice of sensor

ZIR03 SENSOR CIRCULATION from

TKW, TBZ or TWW.

0...120

°C

0

00:118

SEK06

SETPOINT

CIRCULATION

T

Circulation

setpoint tem-

perature

Display for the circulation set-

point calculated from BAS01

DHW TEMP.SETPOINT minus ZIR01

TEMP.REDUCE TSET CIRC..

0...120

°C

25

01:118

AUS

REPORTING

AUS02

MAX FLOW

RATE 24H

Maximum flow

rate in 24h

0...999.9

l/min

25

02:126

AUS03

ENERGY DHW

Partial energy

requirement E

Display for the energy require-

ment for domestic hot water

preparation in kWh. The counter

returns to 0 once 1 Mwh is

reached. This allows the total

yield to be read in MWh and the

partial yield to be read in kWh.

0...999.9

kWh

0

23:006

AUS04

TOTAL

ENERGY DHW

Total energy

requirement

GES

0...999.9

MWh

0

23:013

AUS05

PRIM. PUMP

OPERATING H

Operating

hours of the

primary pump

FRIWA

0...999.9

h

0

02:120

AUS06

CIRC. PUMP

OPERATING H

Operating

hours of the

circulation

pump WWC

0...999.9

h

0

02:121

AUS07

RECHARGE

OPERATING H

Operating

hours for

recharging

NALAD

0...999.9

h

0

02:121

26

03/2024 Item no. 215790 EA no. 1321
