LE NARDO

Codice

Code

Descrizione

Description

Modello

Model

LEOGEA

GRIGLIA ESTERNA ANTI-INSETTO

Griglia circolare anti-insetto per esterno in alluminio verniciata bianca RAL

9010.

OUTDOOR ANTI-INSECT CIRCULAR GRILLE Aluminium outdoor anti-insect

grille painted white RAL 9010.

LEONARDO

(all models)

LEOCD125

DIFFUSORE CIRCOLARE COANDA DN125

Diffusore circolare ad effetto Coanda in lamiera zincata verniciata RAL

9010. DN125

COANDA CIRCULAR DIFFUSER DN125 Circular diffuser with Coanda effect

in galvanised sheet metal painted RAL 9010. DN125

LEONARDO

(all models)

LEONPL125

GIUNTO DN125

Giunto metallico MM con guarnizioni per condotto CABD125.

JOINT DN125

Metal joint MM with gaskets for duct CABD125.

LEONARDO

(all models)

LEODT125

TEE DISTRIBUZIONE CONDOTTO DN125

Tee di connessione con guarnizioni per condotto CABD125.

CONDUCTING TEE DN125 CONNECTING

Tee with gaskets for CABD125 duct.

LEONARDO

(all models)

LEOPL200

LEOPL400

PLENUM ATTACCO SINGOLO POSTERIORE

Plenum con attacco singolo posteriore Ø125 per condotto CABD125.

Plenum realizzato con pro

fili in alluminio estruso anti ossidazione e

rivestito di materiale isolante.

PLENUM WITH SINGLE REAR CONNECTION

Plenum box with single rear connection Ø125 for CABD125 duct. Plenum

box made of extruded anti-oxidation aluminium pro

files and coated with

insulating material.

LEONARDO

(all models)

PLENUM ATTACCO DOPPIO POSTERIORE

Plenum con attacco doppio posteriore Ø125 per condotto CABD125.

Plenum realizzato con pro

fili in alluminio estruso anti ossidazione e rivestito

di materiale isolante.

PLENUM WITH DOUBLE REAR CONNECTION

Plenum box with double rear connection Ø125 for CABD125 duct.

Plenum box made of extruded anti-oxidation aluminium pro

files and coated

with insulating material.

LEONARDO

(all models)

LEOPLL200

PLENUM ATTACCO SINGOLO LATERALE

Plenum con attacco singolo laterale Ø125 per condotto CABD125.

Plenum realizzato con profili in alluminio estruso anti ossidazione e rivestito

di materiale isolante.

SINGLE SIDE CONNECTION PLENUM

Plenum with single side connection Ø125 for CABD125 duct.

The plenum is constructed with anti-oxidation extruded aluminum profiles

coated with insulating material

LEONARDO

(all models)
