DP BIG MONO
WORKING CONDITIONS
SPECIFICATIONS
B
C
A
120 | DP BIG filter housings
Max working pressure ______8,3 bar (120 psi)
Max working temperature_______45°C (113°F)
Min working temperature________4°C (39,2°F)
DP BIG MONO clear housings
HOUSINGS WITH PLASTIC BSP THREADS
Non-toxic materials, suitable for drinking water.
Head: reinforced polypropylene.
Clear bowl: PET.
Blue bowl: reinforced polypropylene.
O-ring: EPDM.
Breather-valve: body polypropylene, o-ring EPDM.
CODE
RA1800711
RA1800911
MODEL
SUITABLE
CARTRIDGE
SUITABLE
CARTRIDGE
IN/OUT
IN/OUT
DIMENSIONS mm
RA1700711
RA1700911
RA1700721
RA1700921
RA1700712
RA1700912
RA1700722
RA1700922
DP BIG 10 MONO - 1” IN TS
DP BIG 10 MONO - 1”1/2 IN TS
DP BIG 20 MONO - 1” IN TS
DP BIG 20 MONO - 1”1/2 IN TS
DP BIG 10 MONO - 1” NPT IN TS
DP BIG 10 MONO - 1”1/2 NPT IN TS
DP BIG 20 MONO - 1” NPT IN TS
DP BIG 20 MONO - 1”1/2 NPT IN TS
DP BIG 10 MONO - 1” IN AB
DP BIG 10 MONO - 1”1/2 IN AB
DP BIG 20 MONO - 1” IN AB
DP BIG 20 MONO - 1”1/2 IN AB
DP BIG 10 MONO - 1” NPT IN AB
DP BIG 10 MONO - 1”1/2 NPT IN AB
DP BIG 20 MONO - 1” NPT IN AB
DP BIG 20 MONO - 1”1/2 NPT IN AB
10”
10”
20”
20”
10”
10”
20”
20”
10”
10”
20”
20”
10”
10”
20”
20”
1”
1”1/2
1”
1”1/2
1”
1”1/2
1”
1”1/2
1”
1”1/2
1”
1”1/2
1”
1”1/2
1”
1”1/2
A
B
C
185
185
360
360
617
617
360
360
617
617
360
360
617
617
360
360
617
617
190
190
190
190
190
190
190
190
190
190
190
190
190
190
190
190
185
185
HOUSINGS WITH PLASTIC NPT THREADS
CODE
RA1800721
RA1800921
MODEL
DIMENSIONS mm
A
B
C
185
185
185
185
DP BIG MONO blue housings
HOUSINGS WITH PLASTIC BSP THREADS
CODE
RA1800712
RA1800912
MODEL
SUITABLE
CARTRIDGE
SUITABLE
CARTRIDGE
IN/OUT
IN/OUT
DIMENSIONS mm
A
B
C
185
185
185
185
HOUSINGS WITH PLASTIC NPT THREADS
CODE
RA1800722
RA1800922
MODEL
DIMENSIONS mm
A
B
C
185
185
185
185
