DP BIG M MONO

WORKING CONDITIONS

SPECIFICATIONS

B

C

A

Max working pressure ______8,3 bar (120 psi)

Max working temperature_______45°C (113°F)

Min working temperature________4°C (39,2°F)

Non-toxic materials, suitable for drinking water.

Head: reinforced polypropylene.

Clear bowl: PET.

Blue bowl: reinforced polypropylene.

O-ring: EPDM.

Breather-valve: body polypropylene, o-ring EPDM.

Manometers: radial type, pressure range 0-12 bar, 0-170 psi.

DP BIG M MONO clear housings with 2 manometers

HOUSINGS WITH PLASTIC BSP THREADS

CODE

RA1800731

RA1800931

MODEL

SUITABLE

CARTRIDGE

IN/OUT

DIMENSIONS mm

RA1700731

RA1700931

CODE

RA1800732

RA1800932

MODEL

SUITABLE

CARTRIDGE

IN/OUT

DIMENSIONS mm

RA1700732

RA1700932

DP BIG M 10 MONO - 1” IN TS

DP BIG M 10 MONO - 1”1/2 IN TS

DP BIG M 20 MONO - 1” IN TS

DP BIG M 20 MONO - 1”1/2 IN TS

DP BIG M 10 MONO - 1” IN AB

DP BIG M 10 MONO - 1”1/2 IN AB

DP BIG M 20 MONO - 1” IN AB

DP BIG M 20 MONO - 1”1/2 IN AB

10”

10”

20”

20”

10”

10”

20”

20”

1”

1”1/2

1”

1”1/2

1”

1”1/2

1”

1”1/2

A

B

C

185

185

425

425

682

682

DP BIG M MONO blue housings with 2 manometers

HOUSINGS WITH PLASTIC BSP THREADS

A

B

C

185

185

435

435

682

682

190

190

190

190

190

190

190

190

185

185

185
