DP BIG S TRIO

WORKING CONDITIONS

SPECIFICATIONS

B

C

A

132 | DP BIG filter housings

Max working pressure ______8,3 bar (120 psi)

Max working temperature _______45°C (113°F)

Min working temperature________4°C (39,2°F)

DRAIN FUNNEL

Back-flow

preventing device

UNI EN 1717-11/2002

Non-toxic materials, suitable for drinking water.

Head: reinforced polypropylene.

Clear bowl: PET.

Blue bowl: reinforced polypropylene.

O-ring: EPDM.

Breather-valve: body polypropylene, o-ring EPDM.

Discharge ball-valve: CW 617 N brass nickel plated.

Drain funnel: reinforced polypropylene.

➝

DP BIG S TRIO clear housings with discharge valves

HOUSINGS WITH PLASTIC BSP THREADS

CODE

RA1803733

RA1803933

MODEL

SUITABLE

CARTRIDGE

IN/OUT

DIMENSIONS mm

RA1703733

RA1703933

DP BIG S TRIO blue housings with discharge valves

HOUSINGS WITH PLASTIC BSP THREADS

CODE

RA1803734

RA1803934

MODEL

SUITABLE

CARTRIDGE

IN/OUT

DIMENSIONS mm

RA1703734

RA1703934

DP BIG S 10 TRIO - 1” IN TS

DP BIG S 10 TRIO - 1”1/2 IN TS

DP BIG S 20 TRIO - 1” IN TS

DP BIG S 20 TRIO - 1”1/2 IN TS

DP BIG S 10 TRIO - 1” IN AB

DP BIG S 10 TRIO - 1”1/2 IN AB

DP BIG S 20 TRIO - 1” IN AB

DP BIG S 20 TRIO - 1”1/2 IN AB

10”

10”

20”

20”

10”

10”

20”

20”

1”

1”1/2

1”

1”1/2

1”

1”1/2

1”

1”1/2

A

B

C

185

185

495

495

760

760

A

B

C

185

185

495

495

760

760

590

590

590

590

590

590

590

590

185

185

185

185
