DP BIG PS PM TRIO

WORKING CONDITIONS

SPECIFICATIONS

B

C

A

134 | DP BIG filter housings

Max working pressure ______8,3 bar (120 psi)

Non-toxic materials, suitable for drinking water.

Max working temperature _______45°C (113°F)

Head: reinforced polypropylene.

Min working temperature________4°C (39,2°F)

Clear bowl: PET.

DRAIN PLUG

MANOMETER PLUG

Blue bowl: reinforced polypropylene.

O-ring: EPDM.

Breather-valve: body polypropylene, o-ring EPDM.

Drain plug: nylon.

Manometer plug: CW 614 N brass.

DP BIG PS PM TRIO clear housings with drain and manometer plugs

HOUSINGS WITH PLASTIC BSP THREADS

CODE

MODEL

RA1803765

RA1803965

HOUSINGS WITH PLASTIC NPT THREADS

CODE

MODEL

RA1803755

RA1803955

SUITABLE

IN/OUT

DIMENSIONS mm

DP BIG PS PM TRIO blue housings with drain and manometer plugs

HOUSINGS WITH PLASTIC BSP THREADS

CODE

MODEL

RA1803766

RA1803966

HOUSINGS WITH PLASTIC NPT THREADS

CODE

MODEL

RA1803756

RA1803956

SUITABLE

IN/OUT

DIMENSIONS mm

CARTRIDGE

A

B

C

185

185

SUITABLE

IN/OUT

DIMENSIONS mm

CARTRIDGE

A

B

C

CARTRIDGE

A

B

C

185

185

SUITABLE

IN/OUT

DIMENSIONS mm

CARTRIDGE

A

B

C

185

185

185

185

➝

➝

RA1703765

RA1703965

RA1703755

RA1703955

RA1703766

RA1703966

RA1703756

RA1703956

DP BIG PS PM 10 TRIO - 1” IN TS

DP BIG PS PM 10 TRIO - 1”1/2 IN TS

DP BIG PS PM 20 TRIO - 1” IN TS

DP BIG PS PM 20 TRIO - 1”1/2 IN TS

DP BIG PS PM 10 TRIO - 1” NPT IN TS

DP BIG PS PM 10 TRIO - 1”1/2 NPT IN TS

DP BIG PS PM 20 TRIO - 1” NPT IN TS

DP BIG PS PM 20 TRIO - 1”1/2 NPT IN TS

DP BIG PS PM 10 TRIO - 1” IN AB

DP BIG PS PM 10 TRIO - 1”1/2 IN AB

DP BIG PS PM 20 TRIO - 1” IN AB

DP BIG PS PM 20 TRIO - 1”1/2 IN AB

DP BIG PS PM 10 TRIO - 1” NPT IN AB

DP BIG PS PM 10 TRIO - 1”1/2 NPT IN AB

DP BIG PS PM 20 TRIO - 1” NPT IN AB

DP BIG PS PM 20 TRIO - 1”1/2 NPT IN AB

10”

10”

20”

20”

10”

10”

20”

20”

10”

10”

20”

20”

10”

10”

20”

20”

1”

1”1/2

1”

1”1/2

1”

1”1/2

1”

1”1/2

1”

1”1/2

1”

1”1/2

1”

1”1/2

1”

1”1/2

405

405

670

670

405

405

670

670

405

405

670

670

405

405

670

670

590

590

590

590

590

590

590

590

590

590

590

590

590

590

590

590

185

185

185

185

185

185

185

185
