HYDRA RAINMASTER
S
E
L
F
-
C
L
E
A
N
I
N
G
F
I
L
T
E
R
S
WORKING CONDITIONS
SPECIFICATIONS
B
C
A
Max working pressure:
BSP versions ____________8 bar (116 psi)
NPT versions ___________8,6 bar (125 psi)
Min working pressure _______1,8 bar (26 psi)
Max working temperature ______45°C (113°F)
Min working temperature _______4°C (39,2°F)
DRAIN FUNNEL
Back-flow
preventing device
UNI EN 1717-11/2002
HYDRA RAINMASTER DUO RAH with GAC cartridge
HOUSINGS WITH BRASS BSP THREADS
CODE
MODEL
SELF
POST
CLEANING
CARTRIDGE
NOMINAL
NOMINAL
FILTRATION
FILTRATION
MICRON
MICRON
IN/OUT
FLOW
RATE l/h
DIMENSIONS mm
A
B
C
HOUSINGS WITH PLASTIC BSP THREADS
CODE
MODEL
HOUSINGS WITH PLASTIC NPT THREADS
CODE
MODEL
SELF
POST
CLEANING
CARTRIDGE
NOMINAL
NOMINAL
FILTRATION
FILTRATION
MICRON
MICRON
SELF
POST
CLEANING
CARTRIDGE
NOMINAL
NOMINAL
FILTRATION
FILTRATION
MICRON
MICRON
IN/OUT
IN/OUT
FLOW
RATE l/h
FLOW
RATE l/h
DIMENSIONS mm
A
B
C
DIMENSIONS mm
A
B
C
For GAC cartridge specifications see LA at page 253
VARIANTS AVAILABLE ON MINIMUM QUANTITY:
Some items in the list are subject to minimum order quantities and/or to longer delivery term.
Non-toxic materials, suitable for drinking water.
Head: reinforced polypropylene.
Bowl: PET.
O-rings: EPDM.
Breather-valve: body stainless steel, o-ring EPDM.
IN/OUT brass threads: CW 617 N brass.
Discharge ball-valve: CW 617 N brass nickel plated.
Drain funnel: reinforced polypropylene.
189 | multi-stage self-cleaning filters
➝
RA6096214
HYDRA RAINMASTER DUO
RAH LA 1/2” OT
90
-
1/2”
1900
390
228
107
RA6096224
HYDRA RAINMASTER DUO
RAH LA 3/4” OT
90
-
3/4”
2600
390
228
107
RA6096234
HYDRA RAINMASTER DUO
RAH LA 1” OT
90
-
1”
2900
390
228
107
RA6096215
HYDRA RAINMASTER DUO
RAH LA 1/2” IN
90
-
1/2”
1900
390
228
107
RA6096225
HYDRA RAINMASTER DUO
RAH LA 3/4” IN
90
-
3/4”
2600
390
228
107
RA6096230
HYDRA RAINMASTER DUO
RAH LA 1” IN
90
-
1”
2900
390
228
107
RA6096226
HYDRA RAINMASTER DUO
RAH LA 3/4” NPT IN
90
-
3/4”
2600
390
228
107
RA6096236
HYDRA RAINMASTER DUO
RAH LA 1” NPT IN
90
-
1”
2900
390
228
107
- HYDRA RAINMASTER DUO with RLH or RSH prefilter
cartridges.
