Fine sediment filtration.
Average life-span: 6-12 months.
Maintenance: surface scraping every 2-3 months.
Remark - Use a pre-filter to protect the cartridge.
C
B
C
A
B
AB cartridges are available in a variety of:
CONFIGURATIONS:
- SX standard configuration double open end
(DOE) available for every height and diameter.
- BX proprietary configuration with double o-ring
collar 45 mm, suitable to PLUS 3P BX
housings, DP housings, K DP housings.
MODELS:
- AB MIGNON series 5”M OD 1.77” ID 0.71, SX
configuration.
- AB-V series 10” OD 1.77” ID 0.71, SX
configuration.
- AB series from 4” to 40” OD 2.40” ID 1.10”,
SX, BX configurations.
CERTIFICATIONS
AB cartridges are tested and certified under the most
stringent procedures worldwide, in compliance with DM
25 (Italy), with the sanitary certification EAC/
Ghostreghistrazia (Russia) and WaterMark (Australia).
Max working temperature ______45°C (113°F)
Non-toxic materials, suitable for drinking water.
Min working temperature _______4°C (39,2°F)
Filter medium: ceramic, self-supporting frame.
End caps: polypropylene.
Flat seals SX: SEBS with antimicrobial technology.
O-rings BX: EPDM.
Cartridges made with ceramic filtering medium providing very fine filtration with good water
flow, designed for water clarification, filtration at 0.45 micron. Height from 4” to 20”.
AB SX
CERAMIC WITH DOUBLE OPEN END (DOE)
COD
E
MODEL
NOMINA
L
NOMINA
L
RECOMMENDE
D
DIMENSIONSMM
A
OD 1,77” x ID 0,71”
RA5260102
AB MIGNON SX 0,45 mcr
RE5155102
AB 10 V SX 0,45 mcr
OD 2,40” x ID 1,10”
RA5261102
AB 4 SX 0,45 mcr
RA5262102
AB 5 SX 0,45 mcr
RA5264102
AB 7 SX 0,45 mcr
RA5265102
AB 10 SX 0,45 mcr
RA5267102
AB 20 SX 0,45 mcr
AB BX
CERAMIC WITH DOUBLE O-RING COLLAR 45 MM
HEIGHT
FILTRATION
FLOW RATE l/h
A
B
C
MICRON
5” M
0,45
80
122
50
20
10”
0,45
200
250
50
20
4”
0,45
120
101
70
30
5”
0,45
150
125
70
30
7”
0,45
200
173
70
30
10”
0,45
300
250
70
30
20”
0,45
500
505
70
30
236 | sediment filter cartridges
AB ceramic
AB
ceramic
WORKING CONDITIONS
SPECIFICATIONS
COD
E
MODEL
NOMINA
L
NOMINA
L
RECOMMENDE
D
DIMENSIONSMM
OD 2,40” x ID 1,10”
RA5262202
AB 5 BX 0,45 mcr
RA5264202
AB 7 BX 0,45 mcr
RA5265202
AB 10 BX 0,45 mcr
RA5267202
AB 20 BX 0,45 mcr
MICRON
5”
0,45
7”
0,45
10”
0,45
20”
0,45
150
125
70
30
200
173
70
30
300
250
70
30
500
505
70
30
FLOW RATE vs PRESSURE DROP Δp
Tests carried on 10” elements type AB 10 SX.
Testing mode: 20°C, 3 BAR
0,45 micron
3
2,5
2
1,5
1
0,5
0
0
50
100
150
200
Flow rate [l/h]
250
300
350
HEIGHT FILTRATION
FLOW RATE l/h
A
B
C
Δ
p
[
b
a
r
]
