RA stainless steel washable net
Sediment filtration.
Average life-span: from 3 to 5 years.
Maintenance: wash every month at least.
WORKING CONDITIONS
Max working temperature ___80°C (176°F)
Min working temperature ____4°C (39,2°F)
SPECIFICATIONS
Non-toxic materials, suitable for drinking water.
Filter medium and inner armouring: stainless steel net AISI 316.
Inner core and end caps: polypropylene.
Flat seals SX: SEBS with antimicrobial technology.
O-rings BX and CX: EPDM.
RA A
stainless steel washable net AISI 316
Cartridges with stainless steel net and stainless steel inner armouring, with consistent water
flow and very low pressure drop, standard filtration at 70 micron. Easy-to-wash filter net, long
term durability of the materials and high collapse resistance make this cartridge range the most
suitable for well water filtration. Available in 2 main versions: RA A made with AISI 316 stainless
steel, RA C made with AISI 304 stainless steel. Height from 4” to 20”.
RA A SX
STAINLESS STEEL AISI 316 WASHABLE NET WITH DOUBLE OPEN END (DOE)
A
COD
E
MODEL
NOMINA
L
NOMINA
L
RECOMMENDE
D
DIMENSIONSMM
C
B
C
A
B
RA cartridges are available in a variety of:
CONFIGURATIONS:
- SX standard configuration double open end
(DOE) available for every height and diameter.
- BX proprietary configuration with double o-ring
collar 45 mm, suitable to PLUS 3P BX
housings, DP housings, K DP housings.
- CX proprietary configuration with double o-ring
collar 57 mm, suitable to PLUS 3P CX, K DP
housings.
MODELS:
- RA MIGNON series 5”M OD 1.77” ID 0.71, SX
configuration.
- RA series from 4” to 20” OD 2.40” ID 1.10”,
SX, BX, CX configurations.
VARIANTS AVAILABLE
ON MINIMUM QUANTITY:
- Filter rates from 100 to 500 micron.
CERTIFICATIONS
RA cartridges are tested and certified under the most
stringent procedures worldwide, in compliance with DM
25 (Italy), with the sanitary certification ACS (France),
EAC/Ghostreghistrazia (Russia) and WaterMark
(Australia).
RA5060116
RA5061116
RA5062116
RA5064116
RA5065116
RA5067116
RA A BX
OD 1,77” x ID 0,71”
RA MIGNON A SX 70 mcr
OD 2,40” x ID 1,10”
RA 4 A SX 70 mcr
RA 5 A SX 70 mcr
RA 7 A SX 70 mcr
RA 10 A SX 70 mcr
RA 20 A SX 70 mcr
HEIGHT
5” M
4”
5”
7”
10”
20”
FILTRATION
FLOW RATE l/h
A
B
C
MICRON
70
800
122
50
20
70
1000
101
70
30
70
1200
125
70
30
70
1700
173
70
30
70
2500
250
70
30
70
4000
505
70
30
STAINLESS STEEL AISI 316 WASHABLE NET WITH DOUBLE O-RING COLLAR 45 MM
COD
E
MODEL
NOMINA
L
NOMINA
L
RECOMMENDE
D
DIMENSIONSMM
RA5062216
RA5064216
RA5065216
RA5067216
RA A CX
OD 2,40” x ID 1,10”
RA 5 A BX 70 mcr
RA 7 A BX 70 mcr
RA 10 A BX 70 mcr
RA 20 A BX 70 mcr
HEIGHT FILTRATION
MICRON
5”
70
7”
70
10”
70
20”
70
FLOW RATE l/h
A
B
C
1200
125
70
30
1700
173
70
30
2500
250
70
30
4000
505
70
30
STAINLESS STEEL AISI 316 WASHABLE NET WITH DOUBLE O-RING COLLAR 57 MM
COD
E
MODEL
NOMINA
L
NOMINA
L
RECOMMENDE
D
DIMENSIONSMM
RA5065316
RA5067316
OD 2,40” x ID 1,10”
RA 10 A CX 70 mcr
RA 20 A CX 70 mcr
HEIGHT FILTRATION
MICRON
10”
70
20”
70
FLOW RATE l/h
A
B
C
2500
250
70
40
4000
505
70
40
241 | sediment filter cartridges
