Valves

m, e, h, p + AMTROBOX/AMTRONIC/SMARTRONIC

DANAÏS MTII

m, e, h, p + AMTROBOX/AMTRONIC/SMARTRONIC

T [°C]

40 - 600

≥ -20 - ≤ +200

Description

Centred-disc butterfly valve with PFA liner. With lever, manual gearbox, pneumatic

or electric actuator. With wafer-type body (T1), full-lug body (T4) or U-section

body with raised faces (T6). EN, ASME, JIS connections possible.

Applications

In the chemical industry, highly corrosive fluids: toxic and highly corrosive fluids

which cannot be handled by metals or elastomers, thus requiring the sole use of

PFA. Moderately corrosive and aggressive fluids allowing the use of a PFA liner

with a stainless steel valve disc. Fluids requiring absolutely safe handling.

http://shop.ksb.com/catalog/k0/en/product/ES000380

Double-offset butterfly valves

APORIS-DEB02

m, e, p

DANAÏS 150

T [°C]

Class

150

T [°C]

50 - 1200

≥ -50 - ≤ +260

Class

150/300

T [°C]

50 - 600

≥ -50 - ≤ +260

10/16/25/40

100 - 2200

≥ -10 - ≤ +80

Description

Double-offset butterfly valve with epoxy coating. Perfect shut-off in either flow

direction. Flanged ends to EN standards, body and valve disc made of nodular cast

iron.

Applications

Shut-off or control duties; drinking water, seawater, air, water engineering.

Description

Double-offset butterfly valve, with plastomer seat (also in fire-safe design), metal

seat or elastomer seat (FKM [VITON R] or NBR [Nitrile]). Lever or manual gearbox,

pneumatic, electric or hydraulic actuator. Body made of nodular cast iron, cast

steel, stainless steel, aluminium bronze or duplex stainless steel (254 SMO). Wafer-

type body (T1), full-lug body (T4), T4 suitable for downstream dismantling and

dead-end service with counterflange. Connections to EN, ASME, JIS. Fire-safe

design tested and certified to API 607. Fugitive emissions performance tested and

certified to EN ISO 15848-1. ATEX-compliant version in accordance with Directive

2014/34/EU.

Applications

Petroleum, gas, chemical and petrochemical industry, marine applications,

transport of petroleum products and chemicals, sugar industry, geothermal

energy, shipbuilding, low-pressure steam, vacuum service, mining, corrosive fluids,

cleaning agents, highly aggressive fluids, brine, paper and pulp industry, fertilisers.

All applications requiring offset-disc butterfly valves.

http://shop.ksb.com/catalog/k0/en/product/ES000427

Description

Double-offset butterfly valve with plastomer seat or metal seat (fire-safe), without

gland packing, maintenance-free, with lever or manual gearbox, pneumatic,

electric or hydraulic actuator, body made of steel or stainless steel. Wafer-type

body (T1), full-lug body (T4) or flanged body (T7) with flat or raised faces. Body

types T4 and T7 are suitable for dead-end service. Connections to EN, ASME or JIS.

Certified to German TA Luft Technical Guidelines on Air Quality Control.

Applications

Petroleum, gas, chemical and petrochemical industry, nuclear power stations,

onshore and offshore plants; steam, vacuum and all applications requiring offset-

disc butterfly valves; industrial gases (air separation units, GOX and LOX)

http://shop.ksb.com/catalog/k0/en/product/ES000381

≤ 25

25/50
