Lifting station Aqualift F XL Mono / Duo 300 liter tank volume

KESSEL AG

Art. no.

11 009

11 027

11 045

11 064

11 077

11 011

11 029

11 047

11 066

11 079

11 015

11 033

11 051

11 066

11 079

Art. no.

11 010

11 090

11 028

11 100

11 046

11 110

11 065

11 123

11 078

11 012

11 091

11 030

11 101

11 048

11 111

11 067

11 016

11 092

11 034

11 103

11 052

11 113

11 067

11 124

11 080

for free-standing installation in frost-free rooms

TÜV Rheinland Germany type tested and monitored

EN 12050-1

Tank volume: 300 liters

Pump volume: 175 liters

Polyethylene storage chamber

with clean-out opening. Spigots for vertical

inlet Ø 110 mm/160 mm, ventilation Ø 75 mm

and for manual diaphragm pump Ø 32 mm.

Horizontal inlet Ø 50 mm to Ø 200 mm by sawing.

Pumps

Pressure sensor controlled twin wastewater

SPF pumps with multi-vane impeller to pump

wastewater with or without sewage (open

channel passage 40 mm). Pump is rated sub-

mersible (IP 68), pump cable length 5 m. With

sound-absorbing underlay mat (10 mm thick).

Vertical/ horizontal outlet with integrated non-

return valve, with/without closure valve (provi-

ded loose), with elastic hose section or flange.

Pressure outlet:

vertical Ø 110 without closure valve,

horizontal Ø 110 with plastic closure valve or

vertical DN 80 with cast iron closure valve

Comfort control unit

with mains power ON / OFF switch and

multilingual digital display (EN, DE, FR, IT, PL, NL)

showing current operational status, settings and

logbook; control unit is splash proof (IP 54), wall

mounted, voltage 230 V or 400 V at 50 Hz. With

potential-free/BMS contact (optional 230 V).

↗

Accessories: page 127 – 133

Note: Also available in 60 Hz / 400 V

page 104

Mono version with one pump
