KESSEL AG
Catalogue EN 4.1
3.1 Lifting stations 123
Lifting station Aqualift S Compact Mono / Duo Tronic
for installation in a concrete slab / floor
TÜV Rheinland Germany type tested and monitored
Tank volume: 65 liters
Pump volume: 20 liters
Polyethylene storage chamber
for installation in a concrete slab / floor,
installation depth (D) 490 to 620 mm,
with lateral inlet Ø 110 mm.
Installation area 700 × 700 mm.
Upper section and cover
Vertically and laterally adjustable upper section,
with black / recessed cover for on-site tiling,
integrated drain, made of polymer, load class K 3,
with moisture protective sealing flange.
Pump
Single or twin removable GTF pump(s) for
wastewater without sewage, float switch /
air pressure sensor controlled with multi-vane
impeller, with integrated non-return flap,
pumping volume 20 liters (GTF 500 / GTF 1200),
pressure pipe connection Ø 40 mm.
Control unit
Tronic versions with SDS control unit (self-diagnosis
system) for fully automatic pump control, splash
water protected (IP 54), wall mounted.
Power cable length: 5 m
Note: A ventilation pipe must be provided for on site.
↗
Accessories: page 127 – 133
EN 12050-2
Mono version with one pump
GTF pump
Voltage
With recessed cover for on-site tiling
Pumping capacity
Illustration shows Art. no. 280 550XC
380
Ø 580
617
H [m]
10
8
6
4
2
Pump type
GTF500-S1*
GTF 500-S1 resistant*
GTF 1200-S3*
GTF 1200-S3 resistant*
Voltage
230V~50Hz
230V~50Hz
230V~50Hz
230V~50Hz
Amperage
Power P1/P2
RPM
2800min
-1
2800 min
-1
2650 min
-1
2650 min
-1
Pumping Pumping
height
capacity
8m
10m
3
/h
GTF 500
1 2 3 4 5 6 7 8 9 10 11 Q[m
3
/h]
GTF 1200
2.7A
0.6kW/0.36kW
2.7A
0.6kW/0.36kW
6.2A
1.4kW/0.84kW
6.2A
1.4kW/0.84kW
8 m
9 m
9 m
10 m
3
/h
15.5 m
3
/h
15.5 m
3
/h
Illustration shows Art. no. 280 550X
380
Ø 580
617
500-S1
500-S1 resistant
1200-S3
1200-S3 resistant
With black cover
500-S1
500-S1 resistant
1200-S3
1200-S3 resistant
230 V
230 V
230 V
230 V
230 V
230 V
230 V
230 V
Art. no.
280 550X
280 550XC
281 250X
281 250XC
280 550S
280 550SC
281 250S
281 250SC
Art. no.
280 530X
280 530XC
281 230X
281 230XC
280 530S
280 530SC
281 230S
281 230SC
*Definition of S1 and S3-pumps see page 97
Duo version with two pumps
GTF pump
Voltage
With recessed cover for on-site tiling
500-S1
500-S1 resistant
1200-S3
1200-S3 resistant
With black cover
500-S1
500-S1 resistant
1200-S3
1200-S3 resistant
230 V
230 V
230 V
230 V
230 V
230 V
230 V
230 V
3.1
4
5
0
3
2
0
D
D
4
5
0
2
1
0
Ø
1
1
0
3
2
0
2
1
0
3
6
0
Ø
4
0
3
6
0
Ø
4
0
4
0
-
1
7
0
Ø
1
1
0
4
0
-
1
7
0
L
i
f
t
i
n
g
s
t
a
t
i
o
n
s
Always the right choice:
kessel.com/smartselect
