124 3.1 Lifting stations

Lifting station Aqualift S Compact Mono

Catalogue EN 4.1

Voltage

KESSEL AG

Art. no.

280 500X

280 500XC

281 200X

281 200XC

280 500S

280 500SC

281 200S

281 200SC

for installation in a concrete slab / floor

TÜV Rheinland Germany type tested and monitored

Tank volume: 65 liters

Pump volume: 16 liters

Polyethylene storage chamber

for installation in a concrete slab/floor,

installation depth (D) 490 to 620 mm,

with lateral inlet Ø 110 mm.

Installation area 700 × 700 mm.

Upper section and cover

Vertically and laterally adjustable upper section,

with black / recessed cover for on-site tiling,

integrated drain, made of polymer, load class K 3,

with moisture protective sealing flange.

Pump

Single removable GTF pump for wastewater

without sewage, float switch / air pressure sensor

controlled with multi-vane impeller, with integrated

non-return flap, pumping volume 16 liters (GTF 500 /

GTF 1200), pressure pipe connection Ø 40 mm.

Control unit

Tronic versions with SDS control unit (self-diagnosis

system) for fully automatic pump control, splash

water protected (IP 54), wall mounted.

Power cable length: 5 m

Note: A ventilation pipe must be provided for on site.

↗

Accessories: page 127 – 133

Pumping capacity

EN 12050-2

GTF pump

H [m]

10

8

6

4

2

Pump type

GTF500-S1*

GTF 500-S1 resistant*

GTF 1200-S3*

GTF 1200-S3 resistant*

Voltage

230V~50Hz

230V~50Hz

230V~50Hz

230V~50Hz

Amperage PowerP1/P2

2.7A

0.6kW/0.36kW

2.7A

0.6kW/0.36kW

6.2A

1.4kW/0.84kW

6.2A

1.4kW/0.84kW

RPM

2800min

-1

2800 min

-1

2650 min

-1

2650 min

-1

Pumping Pumping

height

capacity

8m

10m

3

/h

GTF 500

1 2 3 4 5 6 7 8 9 10 11 Q[m

3

/h]

GTF 1200

8 m

9 m

9 m

10 m

3

/h

15.5 m

3

/h

15.5 m

3

/h

Illustration shows Art. no. 280 500X

500-S1

500-S1 resistant

1200-S3

1200-S3 resistant

With black cover

500-S1

500-S1 resistant

1200-S3

1200-S3 resistant

230 V

230 V

230 V

230 V

230 V

230 V

230 V

230 V

3

2

0

2

1

0

D

4

5

0

Ø

1

1

0

4

0

-

1

7

0

3

6

0

Ø

4

0

*Definition of S1 and S3-pumps see page 97

380

Ø 580

617

With recessed cover for on-site tiling
