KESSEL AG

Catalogue EN 4.1

4.2

Clean-out Ferrofix Ø 110

Floor drains 255

Art. no.

27 191G

for direct access to piping

Upper section in ABS. With closed cover

and rim 150×150 mm made of stainless

steel AISI 304, class K 3, screwed,

without gasket

148

1

Clean-out Ferrofix Ø 110

for direct access to piping

Upper section in ABS. With closed cover

and rim 150×150 mm made of stainless

steel AISI 304, class L 15, screwed,

without gasket

147

1

Clean-out Ferrofix Ø 110

for direct access to piping

Upper section made of stainless

steel AISI 304. With closed, screw-type cover plate

146×146 mm made of stainless steel AISI 304,

class L 15, gastight and a backwater-proof seal

up to 0.5 bar, tileable

Note: Custom made (delivery time on request)

146

110

Clean-out Ferrofix Ø 110

for direct access to piping

Upper section made of stainless

steel AISI 304. With closed, screw-type cover

plate 146×146 mm made of stainless steel

AISI 304, class L 15, screwed odour-tight,

with gasket, with a backwater-proof seal up

to 0.5 bar

Note: Custom made (delivery time on request)

146

Connection Ø

Ø 110

10

Connection Ø

Ø 110

Art. no.

27 196G

10

Connection Ø

Ø 110

Art. no.

27 177-PLF

Connection Ø

Ø 110

Art. no.

27 177-PL

1 10
