A
RA5018114
RA5020114
RL C BX
RL C 10 SX 50 mcr
10”
RL C 20 SX 50 mcr
20”
A
POLYESTER WASHABLE NET WITH DOUBLE O-RING COLLAR 57 MM
RL C polyester washable net
Average life-span: up to 24 months.
Maintenance: wash every month at least.
C
B
C
B
RL C are available in a variety of:
CONFIGURATIONS:
- SX standard configuration double open end
(DOE) available for every height and diameter.
- BX proprietary configuration with double o-ring
collar 45 mm, suitable to PLUS 3P BX
housings, DP housings, K DP housings.
- CX proprietary configuration with double o-ring
collar 57 mm, suitable to PLUS 3P CX, K DP
housings.
MODELS:
- RL-C series 10” and 20” OD 2.40” ID 1.10”,
SX, BX, CX configurations.
CERTIFICATIONS
RL C cartridges are tested and certified under the most
stringent procedures worldwide, in compliance with DM
25 (Italy), with the sanitary certification EAC/
Ghostreghistrazia (Russia) and WaterMark (Australia).
WORKING CONDITIONS
Max working temperature ______45°C (113°F)
Min working temperature _______4°C (39,2°F)
SPECIFICATIONS
Non-toxic materials, suitable for drinking water.
Filter medium: polyester net.
Armouring and end caps: polypropylene.
Flat seals SX: SEBS with antimicrobial technology.
O-rings BX and CX: EPDM.
RL C
polyester washable net
Washable net cartridges with consistent water flow and very low pressure drop, filtration at 50
micron. The cartridges are manufactured without glue and sealants, nets are included while
molding the structural frame (armouring), designed to provide easier cleaning of the surface, with
height 10” and 20”.
RL C SX
POLYESTER WASHABLE NET WITH DOUBLE OPEN END (DOE)
COD
E
MODEL
NOMINA
L
NOMINA
L
RECOMMENDE
D
DIMENSIONSMM
RA5018214
RA5020214
RL C CX
RL C 10 BX 50 mcr
10”
RL C 20 BX 50 mcr
20”
RA5018314
RA5020314
OD 2,40” x ID 1,10”
RL C 10 CX 50 mcr
RL C 20 CX 50 mcr
2500
250
4000
505
OD 2,40” x ID 1,10”
POLYESTER WASHABLE NET WITH DOUBLE O-RING COLLAR 45 MM
OD 2,40” x ID 1,10”
HEIGHT
FILTRATION
MICRON
50
50
FLOW RATE l/h
A
B
C
2500
250
70
30
4000
505
70
30
COD
E
MODEL
NOMINA
L
NOMINA
L
RECOMMENDE
D
DIMENSIONSMM
HEIGHT
FILTRATION
MICRON
50
50
FLOW RATE l/h
A
B
C
2500
250
70
30
4000
505
70
30
COD
E
MODEL
NOMINA
L
NOMINA
L
RECOMMENDE
D
DIMENSIONSMM
FLOW RATE vs PRESSURE DROP Δp
Tests carried on 10” elements type RL C 10 SX.
Testing mode: 20°C, 3 BAR
50 micron
0,35
0,3
0,25
0,2
0,15
0,1
0,05
0
0
1000
2000
3000
4000
Flow rate [l/h]
5000
6000
7000
HEIGHT
10”
20”
FILTRATION
MICRON
50
50
FLOW RATE l/h
A
B
70
70
C
40
40
239 | sediment filter cartridges
